Debugging

Unfortunately, the computers just “don’t get it”, and they do what we (or the AI) tell them to do, and not what we wanted them to do, and programs fail or crash. GoMLX provides different ways to track down various types of errors. The most commonly used below:

Good old “printf”

It’s convenient and because of Go fast compilation, often a valid way of developing by just logging results to the stdout. During graph building development, often one prints the shape of the Node being operated to confirm (or not) one’s expectations.

Execution Logging

Every Node in the computation graph can be marked for logging during the graph construction phase. This is done by calling Node.SetLogged(msg) or Node.SetLoggedf(format, args...) on the node of interest.

At execution time, the executor (Exec) automatically:

1. Detects all nodes in the graph that have been marked for logging.
2. Appends these nodes as extra outputs to the underlying graph execution, ensuring their tensor values are computed.
3. Retrieves the computed tensor values post-execution and passes the messages, tensor values, and node IDs to the registered LoggerFn callback.
4. Slices out the logged nodes’ values from the final output list returned to the user, making execution logging completely transparent to the caller of Exec.Call (or MustCall).

By default, the executor is configured with DefaultNodeLogger, which prints the graph’s name, the node ID, the message, and the computed value of the tensor to stdout.

• If the message begins with the prefix "#full ", the default logger will output the full tensor value using Tensor.GoStr(). Otherwise, a truncated preview of the tensor is printed.

You can customize this behavior or implement your own logger by calling Exec.SetNodeLogger(loggerFn). The signature for the callback is:

type LoggerFn func(graph *Graph, messages []string, values []*tensors.Tensor, nodes []NodeId)

To disable execution logging entirely, you can call exec.SetNodeLogger(nil).

Example

func SquareAndAddOne(x *Node) *Node {
	xSquared := Mul(x, x)
	// Mark the intermediate square calculation to be logged:
	xSquared.SetLoggedf("#full x^2 intermediate value")

	one := Scalar(x.Graph(), x.DType(), 1.0)
	return Add(xSquared, one)
}

exec := MustNewExec(backend, SquareAndAddOne)

// Option 1: Run with the default logger (prints to stdout)
exec.MustCall([]float32{2.0, 3.0})

// Option 2: Run with a custom logger
exec.SetNodeLogger(func(g *Graph, messages []string, values []*tensors.Tensor, nodes []NodeId) {
	for i, msg := range messages {
		fmt.Printf("Custom Logger: [Node #%d] %s = %v\n", nodes[i], msg, values[i].Value())
	}
})
exec.MustCall([]float32{5.0, 7.0})

Output:

DefaultNodeLogger(Graph "Exec:main.SquareAndAddOne#1"):
	(Node #1) x^2 intermediate value: (Float32)[2]: []float32{4, 9}
Custom Logger: [Node #1] #full x^2 intermediate value = [25 49]

NanLogger

The nanlogger.NanLogger uses GoMLX’s logging infrastructure to monitor for NaN (Not-a-Number) and ±Inf (infinity) values during execution or training.

Debugging numerical instability in deep learning model graphs can be extremely challenging, as NaNs propagate rapidly across operations. NanLogger solves this by tracing specific nodes and identifying the first node (closest to inputs) where a NaN/Inf is detected, capturing its call stack trace and user-defined scope.

Under the hood, tracing a node adds a finite check node to the graph (using graph.IsFinite(node) and graph.LogicalAll) marked with SetLogged(uniqueMessageID). The NanLogger registers itself as the executor’s logger by calling AttachToExec(exec) or AttachToTrainer(trainer). It acts as a pass-through logger: any log messages that do not belong to NanLogger are forwarded to the executor’s previous logger.

Handlers

When a NaN or ±Inf is encountered, it triggers a HandlerFn to report the issue. NanLogger provides several built-in handlers:

• ReportScopeHandler (default): Logs the active scope path of the failure using klog.Infof.
• ReportAllHandler: Logs the active scope path and the full Go call stack trace where Trace was set.
• ReportAndPanicHandler: Logs the active scope and stack trace, and then panics. This is highly useful during active debugging to halt execution immediately.
• DefaultBreakHandler: Logs the details using klog.Errorf.

You can set the desired handler using WithHandler(handlerFn).

Managing Scope and Traces

• Scopes: You can push and pop layers/operation names onto the logger’s scope stack using PushScope("layer_name") and PopScope(). Any trace created will inherit the current scope hierarchy.
• First NaN vs. Continue:
  • TraceFirstNaN(node, scope...): Traces only the first NaN occurrence. If multiple traced nodes are non-finite, only the one closest to the input is handled.
  • TraceAndContinue(node, scope...): Logs the non-finite occurrence but does not stop execution.
  • Trace(node, scope...): Behaves according to the WithStopAtFirst(bool) configuration (default is true).

Example

func MyLayer(l *nanlogger.NanLogger, x *Node) *Node {
	l.PushScope("dense_layer_1")
	defer l.PopScope()

	denominator := Scalar(x.Graph(), x.DType(), 0.0)
	y := Div(x, denominator)
	l.TraceFirstNaN(y, "output_division")
	return y
}

l := nanlogger.New().WithHandler(nanlogger.ReportAndPanicHandler)
exec := MustNewExec(backend, func(x *Node) *Node {
	return MyLayer(l, x)
})
l.AttachToExec(exec)
l.WithHandler(nanlogger.ReportScopeHandler)
_, err := exec.Call([]float32{1.0, 2.0})

Output:

I0720 18:14:08.141136  135770 nanlogger.go:375] NaN/Inf observed for scope ["dense_layer_1" "output_division"]

Node with Stack-Traces

When writing gradient of new operations (or any other debugging) sometimes it’s useful to know exactly where a Node was created. Use Graph.SetTraced(true) to enable all new nodes to include its stack-trace. And Node.Trace() to access it for printing or debugging.
