Overview

GoMLX is built on a few abstractions. Understanding them makes every other part of the library click:

1. Backend — the connection to a hardware backend (CPU, GPU, TPU). It JIT-compiles computation graphs (slow) and executes them efficiently (fast) – all done for you automatically.
2. Graph — a computation graph that you build using a pure Go function.
3. Tensor — a concrete multi-dimensional array (or scalar) value, used as input and output when executing graphs.
4. Store — a scoped storage for named and typed model variables (aka. parameters or weights), as well as hyperparameters of a model.

You can use just the backend and graph for mathematical computing, or add a Store to build trainable models.

Conceptual Workflow

Let’s look at a minimal GoMLX program (stripped of error handling) that calculates the Euclidean distance between 2 tensors:

func MyComputation(x, y *Node) *Node {
	return Sqrt(ReduceAllSum(Square(Sub(x, y))))
}

backend, err := compute.New()
exec, err := NewExec(backend, MyComputation)
results, err := exec.Call([]float32{1.0, 2.0}, []float32{4.0, 6.0})
fmt.Printf("Distance (1,2)->(4,6):  %v\n", results[0])
results, err = exec.Call([]float32{0, 0}, []float32{5, 12})
fmt.Printf("Distance (0,0)->(5,12): %v\n", results[0])

The output is:

Distance (1,2)->(4,6):  float32(5)
Distance (0,0)->(5,12): float32(13)

Behind the scenes, this is what is happening:

sequenceDiagram
    autonumber

    participant Go as Orchestrator<br/>(Go, user code)
    participant Graph as Graph Builder<br/>(Go, symbolic computation)
    participant Backend as Backend<br/>(e.g.: XLA/PJRT)

    Go->>Backend: backend := compute.New()
    Go->>Go: exec := graph.NewExec(backend, MyComputation)

    Note over Go, Backend: Step 3: First execution (triggers build & compile)
    Go->>Graph: exec.Call(inputs)

    activate Graph
    Note right of Graph: Invoke "MyComputation" to build symbolic computation<br/>Uses ops like Sub, Square, ReduceSum, Sqrt
    Graph-->>Backend: Passes symbolic graph
    deactivate Graph

    activate Backend
    Backend->>Backend: Graph.Compile() -> Executable
    Backend->>Backend: Executable.Execute(inputs)
    Backend-->>Go: Returns output tensors
    deactivate Backend

    Note over Go, Backend: Step 4: Second execution with the SAME shape
    Go->>Backend: exec.Call(inputs)

    activate Backend
    Note right of Backend: Graph building & compile skipped!<br/>Uses cached Executable
    Backend->>Backend: Executable.Execute(inputs)
    Backend-->>Go: Returns output tensors
    deactivate Backend

This is the heart of GoMLX. We used a very simple example, but it demonstrates how to efficiently execute math on large tensors in Go.

Below we’ll progressively unpack GoMLX concepts and expand its applicability all the way to training machine learning (ML) models.

Backend

The compute.Backend connects your Go process to a hardware+software backend abstraction capable of executing our computations. Create one at program startup and reuse it everywhere :

import (
	"github.com/gomlx/compute"
	_ "github.com/gomlx/gomlx/backends/default" // Includes default backends.
)

backend, err := compute.New() // auto-selects best available backend
fmt.Printf("Backend: %s\n", backend.Description())

Output:

Backend: xla:cuda - PJRT "cuda" plugin (/home/janpf/.local/lib/go-xla/nvidia/pjrt_c_api_cuda_plugin.so) v0.112 [StableHLO] [1 device(s)]

The backend owns the device memory, compiles graphs to native code, and manages data transfer between “host” (your normal CPU) and device (can be the same CPU or a GPU, TPU, etc). One backend per process is the typical pattern.

The following backends are implemented so far:

• “go”: Pure Go implementation: simple, very portable but slower. It works in WASM also (so it can be used in websites).
• “xla” (or "xla:cpu", "xla:cuda", "xla:tpu"; use "xla:help" for an error with its options): uses Google’s XLA, the same backend used by TensorFlow, Jax and optionally by PyTorch.
• go-darwinml: (experimental, in development) it provides the CoreML (ANE, GPU, CPU) and the MPSGraph (GPU/Metal) backends.

Computation Graphs

A graph is a pure function that describes a computation in terms of *graph.Node values and operations connecting them. GoMLX provides the high-level API to build these graphs. The computation graphs are then JIT-compiled and can be executed very efficiently by the selected backend.

import (
	. "github.com/gomlx/gomlx/core/graph"
)

addFn := func(a, b *Node) *Node {
	fmt.Printf("* building addFn computation graph: a.shape=%s, b.shape=%s\n", a.Shape(), b.Shape())
	return Add(a, b)
}
addExec, err := NewExec1(backend, addFn)
if err != nil {
	log.Fatalf("error creating computation graph: %+v\n", err)
}
v1, err := addExec.Call(1.0, 1.0)
if err != nil {
	log.Fatalf("Failed to compile/execute: %+v", err)
}
fmt.Printf("\t- 1+1=%s\n", v1)
fmt.Printf("\t- 2+2=%s\n", addExec.MustCall(2.0, 2.0))

Output:

* building addFn computation graph: a.shape=(Float64), b.shape=(Float64)
	- 1+1=float64(2)
	- 2+2=float64(4)

Why graphs?

This design gives the backend (XLA in this case) visibility over the entire computation so it can apply aggressive optimizations: operator fusion, memory layout selection, etc. — automatically.

Your Go code never runs on the GPU (or whatever is the accelerator device). Only the compiled graph runs there. This is the same design used by JAX @jax.jit and TensorFlow’s @tf.function.

Nodes are “future values”, not concrete tensors

Inside a graph function, a *graph.Node represents a future value. You cannot inspect its contents during graph construction — only after calling .Call() (or equivalent, like .MustCall1). Operations on nodes describe the graph structure.

The *graph.Node does carry information about the shape (dimensions and data type) of the value though, and they are used during graph building to check compatibility of the nodes for the operations – e.g.: adding an int to a float, or values with different ranks are not valid operations, and return an error.

_, err = addExec.Call(int32(1), float32(1.0))
if err != nil {
	//...
}

Output:

* building addFn computation graph: a.shape=(Int32), b.shape=(Float32)
Error: cannot broadcast Int32 and Float32 for "Add": they have different dtypes
	.../gomlx.github.io/core-concepts/graph/main.go:33
	.../gomlx.github.io/core-concepts/graph/main.go:50

Exception-based Error Handling during Graph Building

Unlike standard Go code where errors are returned as values, GoMLX graph building functions panic (throw exceptions) when shape or type mismatches are found.

• Why? Writing long mathematical formulas would be cluttered and difficult to read if every operation returned an error.
• How it works: Panics only occur during the graph construction phase. The Exec wrapper catches these panics automatically and returns them as standard Go errors (complete with stack traces) when .Call() is invoked.

See more in Error Handling.

Static Shapes & Recompilation Performance Trap

Behind the scenes, the backend compiles the computation graph to a highly optimized native binary for the target hardware. However, this JIT compilation is strictly tied to the static shape (the dimensions and data type) of the input nodes.

• The Trap: If you pass inputs of varying shapes (such as changing batch sizes or sequence lengths) to Exec.Call, GoMLX will JIT-compile a new graph for every new shape it sees. Since JIT compiling a graph is orders of magnitude slower than executing it, this will severely degrade performance.
• Best Practice: Reuse input shapes whenever possible. If your batch or sequence sizes vary, pad your inputs to fixed sizes (such as powers of two or predefined bucket lengths) to reuse already compiled graphs.

Tensors

Tensors hold the inputs and outputs of a graph computation. They represent concrete multi-dimensional array values (including scalar values), defined by their shape (shapes.Shape), which specifies the axes’ dimensions and a data type (dtypes.DType).

Shapes and data types (dtypes)

Every tensor has a shape (e.g. (Float32)[2, 2]), a list of dimension sizes, plus a DType. GoMLX checks shape compatibility at graph construction time, catching mismatches before any computation starts.

You can construct tensors.Tensor objects from standard Go values (like multi-dimensional slices) using FromValue:

// Tensors can be created from Go values, such as multi-dimensional slices
t := tensors.FromValue([][]float32{{1.0, 2.0}, {3.0, 4.0}})
fmt.Printf("Tensor shape: %s\n", t.Shape())
fmt.Printf("Tensor Go value: %v\n", t.Value())

Output:

Tensor shape: (Float32)[2, 2]
Tensor Go value: [[1 2] [3 4]]

Common dtypes include dtypes.Float32, dtypes.Float64, dtypes.Int32, dtypes.Int64, and dtypes.Bool.

Host vs. Device memory

Behind the scenes, a Tensor maintains synchronization between its memory representation in host RAM (local CPU) and accelerator device memory (GPU/TPU):

// Tensors cache data both locally (host CPU) and on accelerator devices.
// Transferring data between CPU and devices has a cost and is done lazily.
fmt.Printf("Has local copy? %v\n", t.HasLocal())

Output:

Has local copy? true

To avoid expensive memory copies, transferring data between host and device is performed lazily only when needed.

Finalizing Tensors

Since the Go Garbage Collector cannot see memory allocated on accelerator devices (like CUDA GPUs), accelerator device memory is best if explicitly managed. When you are done with a tensor, you should explicitly call FinalizeAll (or MustFinalizeAll) to free its device buffers – the GC will also free the memory, but it may hold to it too long.

// Tensors allocate memory on accelerator devices (GPU, TPU).
// Because the Go Garbage Collector cannot track device memory,
// you must finalize tensors that are no longer in use to prevent memory leaks.
err := t.FinalizeAll()

Gradients & Automatic Differentiation

A fundamental requirement for training neural networks is the ability to compute gradients. GoMLX performs automatic symbolic differentiation during the graph building phase. It automatically appends the mathematical operations required for back-propagation directly into the computation graph.

Use the graph.Gradient(loss, targets...) function to calculate the gradient of a scalar node (typically the model’s loss) with respect to a list of target nodes:

func GradFn(x, y *Node) (loss, gradX, gradY *Node) {
	// f(x, y) = x^2 + xy
	loss = Add(Square(x), Mul(x, y))

	// Reduce if inputs are not scalars, as Gradient requires a scalar loss
	scalarLoss := ReduceAllSum(loss)

	// Calculate gradients df/dx and df/dy symbolically
	grads := Gradient(scalarLoss, x, y)
	return loss, grads[0], grads[1]
}

The model.Store and Scopes

To build trainable models, you need a way to declare, retrieve, and update variables (akak. “parameters” or “weights”) that persist across graph executions. The Store is a hierarchical (tree-like) store for model parameters (represented by Variable) and hyperparameters.

It is important to understand the division of responsibilities here:

• model.Store: This is the actual stateful container that physically stores the variable values (tensors representing weights and biases) and hyperparameters of your model in memory. It persists across multiple JIT compilations and graph executions.
• model.Scope: This is a lightweight pointer that represents a specific path or “current directory” within the hierarchical Store (e.g., /layer1). Layer functions accept a *model.Scope and construct or look up variables relative to their current scope, which prevents name collisions and organizes weights cleanly (e.g., /layer1/weights, /layer2/weights).

Model Variables and Executors

Instead of using the basic graph.Exec, neural network architectures use Exec. It is constructed with a Store and automatically handles passing variables as extra inputs and outputs to the compiled graph.

Here is a simple counter that increments a variable in the store on each step:

store := model.NewStore()
counterFn := func(scope *model.Scope, g *Graph) *Node {
	counterVar := scope.VariableWithValue("counter", int32(0))
	counter := AddScalar(counterVar.NodeValue(g), 1)
	counterVar.SetNodeValue(counter)
	return counter
}

exec := model.MustNewExec(backend, store, counterFn)
fmt.Printf("Step 1: %v\n", exec.MustCall1())
fmt.Printf("Step 2: %v\n", exec.MustCall1())
fmt.Printf("Step 3: %v\n", exec.MustCall1())

Output:

Step 1: int32(1)
Step 2: int32(2)
Step 3: int32(3)

Inside the model function, scope.VariableWithValue retrieves or initializes the variable, counterVar.NodeValue(g) returns the node representing its current value, and counterVar.SetNodeValue(counter) updates its value in the store with the computation result.

Scopes and Hierarchical Parameters

A Scope represents a path in the hierarchical store (similar to directories). When building complex model architectures, scopes allow you to separate variables of different layers.

Here is an example of defining a custom denseLayer function and applying it to different sub-scopes using scope.In:

func denseLayer(scope *model.Scope, x *Node, outputDims int) *Node {
	g := x.Graph()
	dtype := x.DType()
	inputDims := x.Shape().Dimensions[1] // x shape is [batch, inputDims]

	// Create weights and biases in the current scope
	weights := scope.VariableWithShape("weights", shapes.Make(dtype, inputDims, outputDims)).NodeValue(g)
	biases := scope.VariableWithShape("biases", shapes.Make(dtype, 1, outputDims)).NodeValue(g)

	// Compute x * weights + biases
	return Add(Dot(x, weights).Product(), biases)
}

modelFn := func(scope *model.Scope, x *Node) *Node {
	// Use scope.In to partition variable names under sub-scopes:
	h := denseLayer(scope.In("layer1"), x, 3) // variables: /layer1/weights, /layer1/biases
	y := denseLayer(scope.In("layer2"), h, 1) // variables: /layer2/weights, /layer2/biases
	return y
}

Using scope.In("layer1") ensures that the weights and biases of the first layer are stored under paths like /layer1/weights and /layer1/biases, avoiding conflicts with other layers.

If we run the model function, we can inspect all of the variables registered in the store:

// We can inspect all variables in the store:
for v := range store.IterVariables() {
	fmt.Printf("Variable: %s, shape: %s\n", v.Path(), v.Shape())
}

Output:

Variable: /counter, shape: (Int32)
Variable: /layer1/weights, shape: (Float32)[2, 3]
Variable: /layer1/biases, shape: (Float32)[1, 3]
Variable: /layer2/weights, shape: (Float32)[3, 1]
Variable: /layer2/biases, shape: (Float32)[1, 1]
Variable: /#rngState, shape: (Uint64)[3]

Training a Model

Training a model in GoMLX brings together all the building blocks: the backend, the Store for tracking weights, Dataset iteration, and the Trainer / Loop.

Here is a complete, working example that trains a small Multi-Layer Perceptron (MLP) to overfit (memorize) an image. The network learns a function $f(x, y) \to (r, g, b)$ that maps normalized pixel coordinates to the corresponding color at that location:

// 1. Prepare training data: mapping (x, y) coordinates to (r, g, b) colors
inputs := make([][]float32, 0, width*height)
labels := make([][]float32, 0, width*height)

for y := range height {
	for x := range width {
		// Normalize coordinates to [-1.0, 1.0] for stable neural network training
		nx := float32(x)/float32(width)*2.0 - 1.0
		ny := float32(y)/float32(height)*2.0 - 1.0
		inputs = append(inputs, []float32{nx, ny})

		r, g, b, _ := img.At(bounds.Min.X+x, bounds.Min.Y+y).RGBA()
		labels = append(labels, []float32{float32(r) / 65535.0, float32(g) / 65535.0, float32(b) / 65535.0})
	}
}

backend := compute.MustNew()
store := model.NewStore()

// 2. Create an InMemoryDataset from the prepared coordinates and pixel colors
ds, err := dataset.InMemoryFromData(backend, "image_pixels", []any{inputs}, []any{labels})
if err != nil {
	log.Fatalf("failed to create dataset: %v", err)
}
// Configure dataset to yield random batches of size 512 continuously (infinitely)
ds.BatchSize(512, false).Shuffle().Infinite(true)

// 3. Define the neural network model function (MLP)
modelFn := func(scope *model.Scope, spec any, inputs []*Node) []*Node {
	x := inputs[0] // shape: [batch_size, 2]

	h := denseLayer(scope.In("layer1"), x, 64)
	h = activation.Relu(h)
	h = denseLayer(scope.In("layer2"), h, 64)
	h = activation.Relu(h)
	h = denseLayer(scope.In("layer3"), h, 64)
	h = activation.Relu(h)

	// Output RGB values mapped to [0.0, 1.0] using Sigmoid
	y := Sigmoid(denseLayer(scope.In("output"), h, 3))
	return []*Node{y}
}

// 4. Initialize Trainer with Adam optimizer and Mean Squared Error (MSE) loss
trainer := train.NewTrainer(
	backend,
	store,
	modelFn,
	loss.MeanSquaredError,
	optimizer.Adam().LearningRate(0.003).Done(),
	nil, // Train step metrics (optional)
	nil, // Eval metrics (optional)
)

// 5. Run the training loop for -steps (default 5000) steps
loop := train.NewLoop(trainer)
// Register a simple callback to print loss metrics periodically
train.EveryNSteps(loop, 1000, "log_metrics", 0, func(l *train.Loop, metrics []*tensors.Tensor) error {
	fmt.Printf("Step %5d: MSE Loss = %.6f (moving average = %.6f)\n", l.LoopStep, metrics[0].Value(), metrics[1].Value())
	return nil
})

fmt.Println("Starting training loop...")
_, err = loop.RunSteps(ds, *trainSteps)
if err != nil {
	log.Fatalf("training failed: %v", err)
}
fmt.Println("Training finished!")

Output:

Starting training loop...
Step   999: MSE Loss = 0.000038 (moving average = 0.000040)
Step  1999: MSE Loss = 0.000067 (moving average = 0.000027)
Step  2999: MSE Loss = 0.000012 (moving average = 0.000030)
Step  3999: MSE Loss = 0.000010 (moving average = 0.000019)
Step  4999: MSE Loss = 0.000013 (moving average = 0.000018)
Training finished!
Successfully reconstructed image saved to reconstructed.png

Each of these pieces — the backend, model, store, loss, optimizer, and training loop — is independently replaceable:

• Swap out the Adam optimizer for optimizers.StochasticGradientDescent() or any other strategy.
• Modify the neural network definition or layers without changing how the training loop or dataset works.
• Load weights (store) from a different checkpoint, or create the average of the last 10 checkpoints.
• Switch the backend from CUDA GPU to Metal/CPU without altering any machine learning code.

That’s what makes GoMLX powerful for research and experimentation.

See more details in: Datasets, Hyperparameters, Losses, Optimizers, Metrics, Checkpointing (Saving)
